1964-1972 A-Body TQ Series CoilOvers – Rear – Pair

$5,008.00 inc. GST

TQ Series rear CoilOvers give your 1968-1972 GM A-Body competition-grade handling with dual compression adjustment and rebound adjustment for precise tuning.

Description

TQ Series rear CoilOvers give your 1968-1972 GM A-Body competition-grade handling with dual compression adjustment and rebound adjustment for precise tuning. Remote reservoirs provide consistent fluid temps in all environments, as well as easier access to compression tuning knobs. TQ “Track Quality” Series provides single rebound adjustment combined with dual stage – high speed and low speed – compression adjustment. The high speed adjustment feature allows tuning of instances that might induce a high speed excursion of the piston rod. This includes rapid changes in suspension loading such as quick directional transitions in autocross competition. The high speed adjustment also allows fine tuning for impact harshness typically found during street driving such as pot holes, speed bumps, and other road irregularities. Low speed adjustment allows tuning of ride quality, as well as the general cornering characteristics of typical road course and winding road cornering use. TQ Series CoilOvers are the ultimate choice for autocross, track days, drag racing and other extreme use.

With a large 1.834″ piston, heavy duty 5/8″ shaft, and impact forged bodies, TQ Series CoilOvers are built to perform and built to last. They’re backed by our exclusive 1,000,001 mile warranty. RideTech develops our shock calibrations and spring rates through thousands of cross-country test miles, on our exclusive test track and at competition events from coast to coast. We understand the suspension needs of your Chevelle, Malibu, GTO, 442, Lemans, Tempest, Skylark or El Camino better than any other company. This coil-over system includes two rear triple adjustable TQ Series CoilOver shocks with remote reservoirs on a 30″ braided line and two Hyperco coil springs with proper spring rate.

NOTES:

— A RideTech Suspension Specialist with contact you to discuss your setup prior to shipping.

— This product requires RideTech Bolt-On 4-Link for proper installation.


INSTRUCTIONS

11226111_FOX_ADJUSTER_KNOB.PDF

Installation Instructions

COILOVER_INSTRUCTIONS.PDF

Assembly Instructions

19-SHOCK-TUNING-GUIDE.PDF

Adjustable Shock tuning Guide

TQ_INTAKE_SHEET.PDF

Triple Adj Custom Valve Form

ADDITIONAL INFORMATION
STOCK OR AFTERMARKET REAR-END
SUSPENSION LOCATION Rear
SUSPENSION TYPE Coil-Over Suspension
YEAR
MAKE
MODEL
VEHICLE FITMENT
MAKE MODEL YEAR
BUICK GRAN SPORT 1965 – 1967
BUICK GS 1970 – 1972
BUICK GS 350 1968 – 1969
BUICK GS 400 1968 – 1969
BUICK GS 455 1970 – 1972
BUICK SKYLARK 1964 – 1972
BUICK SPECIAL 1964 – 1969
BUICK SPORTWAGON 1964 – 1972
CHEVROLET CHEVELLE 1964 – 1972

Additional information

Weight 23 kg
Stock or Aftermarket Rear-End

GearFX or Moser Rear-End, Stock 10/12 Bolt or Currie
